The TPS2231RGPT can drive up to 10,000 pF of capacitive load, but it's recommended to limit it to 4,700 pF for optimal performance.
To ensure proper power-up and configuration, make sure to follow the recommended power-up sequence, connect the EN pin to a valid logic level, and use an external pull-up resistor on the EN pin if necessary.
To minimize EMI and noise, place the TPS2231RGPT close to the power source, use a solid ground plane, and keep the input and output traces short and away from sensitive analog signals. Also, use a common-mode choke or ferrite bead on the output to reduce EMI.
The TPS2231RGPT has a built-in overcurrent protection feature that limits the output current to 2.5 A. To detect faults, monitor the FAULT pin, which goes low when an overcurrent or overtemperature condition occurs. You can also use an external circuit to detect overvoltage or undervoltage conditions.
The TPS2231RGPT has a thermal derating of 13.3 mW/°C above 25°C. To calculate the maximum ambient temperature, use the formula: T_A(max) = T_J(max) - (P_D(max) / θ_JA), where T_A(max) is the maximum ambient temperature, T_J(max) is the maximum junction temperature (150°C), P_D(max) is the maximum power dissipation, and θ_JA is the junction-to-ambient thermal resistance (45°C/W).
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS2231RGPT Overview
Use the download button to access the TPS2231RGPT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS22,
or try a keyword search, such as Power Management Circuits
