A good PCB layout for the TPS2373-3RGWR involves placing the device close to the PoE input, using a solid ground plane, and keeping the power traces short and wide. Additionally, decoupling capacitors should be placed close to the device's power pins.
To ensure proper power-up and configuration, follow the recommended power-up sequence, connect the EN pin to a valid voltage source, and configure the ISET pin to set the current limit. Also, ensure the device is properly bypassed with capacitors.
The TPS2373-3RGWR has a thermal pad that must be connected to a solid ground plane to dissipate heat. Ensure good airflow, use a heat sink if necessary, and follow the recommended thermal design guidelines to prevent overheating.
To troubleshoot issues, check the input voltage, ensure proper power-up sequencing, verify the EN pin is properly configured, and check for overheating. Use an oscilloscope to monitor the device's signals and consult the datasheet for troubleshooting guidelines.
Yes, the TPS2373-3RGWR is sensitive to EMI/EMC. Ensure proper shielding, use a common-mode choke, and follow good PCB layout practices to minimize EMI/EMC issues. Consult the datasheet and application notes for more information.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS2373-3RGWR Overview
Use the download button to access the TPS2373-3RGWR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS23,
or try a keyword search, such as Power Management Circuits
