The maximum current rating of the TPS2410PW is 1.5A per channel, with a total current limit of 3A for both channels.
To configure the TPS2410PW for hot-swap applications, connect the HS pin to VCC, and the EN pin to a logic high signal. This enables the hot-swap functionality, allowing the device to handle live insertion and removal of loads.
The FAULT pin is an open-drain output that indicates when a fault condition occurs, such as overcurrent, undervoltage, or overtemperature. It can be connected to a microcontroller or other logic circuit to trigger a response to the fault condition.
Yes, the TPS2410PW is rated for operation up to 125°C, making it suitable for high-temperature applications. However, the device's performance and reliability may degrade at extreme temperatures, so proper thermal management is essential.
To ensure EMC with the TPS2410PW, follow proper PCB layout and design guidelines, such as keeping the device's power and ground pins close together, using a solid ground plane, and minimizing loop areas. Additionally, consider using electromagnetic interference (EMI) filters or shielding to reduce emissions.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
TPS2410PW Overview
Use the download button to access the TPS2410PW schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS24,
or try a keyword search, such as Other Signal Circuits
