- Part Number TPS25750SRSMR
- Manufacturer Texas Instruments
- Pin Count 33
- Part Category Integrated Circuit
- Package Category Quad Flat No-Lead
- Footprint Name Quad Flat No-Lead - RSM0032B
- Released Date Jan 13, 2021
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
TPS25750SRSMR Details
-
Manufacturer Part Number:
TPS25750SRSMR
-
Brand Name:
Texas Instruments
-
Pbfree Code:
Yes
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Not Recommended
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.90
-
Date Of Intro:
2020-11-14
-
Manufacturer:
Texas Instruments
-
YTEOL:
4
-
Adjustable Threshold:
YES
TPS25750SRSMR Frequently Asked Questions (FAQs)
-
A good PCB layout for the TPS25750SRSMR involves placing the input capacitors close to the VIN pin, using a solid ground plane, and keeping the high-current paths short and wide. TI provides a recommended layout in the datasheet and application notes.
-
Choose an input capacitor with a voltage rating that exceeds the maximum input voltage, a capacitance value between 4.7uF to 10uF, and an ESR that meets the datasheet specifications. X5R or X7R ceramic capacitors are good options.
-
The TPS25750SRSMR can deliver up to 3A of output current, but this may vary depending on the input voltage, output voltage, and thermal conditions. Refer to the datasheet for more information on output current capabilities.
-
The output voltage of the TPS25750SRSMR can be adjusted by using a resistor divider network between the FB pin and the output voltage. The datasheet provides a formula to calculate the required resistor values.
-
The EN (enable) pin is used to turn the regulator on or off. When the EN pin is high, the regulator is enabled, and when it's low, the regulator is disabled. This pin can be used to implement power sequencing or to turn off the regulator during shutdown.
