A good PCB layout for the TPS25762CQRQLRQ1 involves placing the input capacitors close to the VIN pin, using a solid ground plane, and keeping the high-current paths short and wide. It's also recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane.
When choosing an input capacitor for the TPS25762CQRQLRQ1, consider the voltage rating, capacitance value, and ESR (Equivalent Series Resistance). A capacitor with a voltage rating of at least 1.5 times the maximum input voltage, a capacitance value of 10uF to 22uF, and an ESR of less than 100mΩ is recommended.
The TPS25762CQRQLRQ1 can deliver up to 3A of output current, but this may vary depending on the input voltage, output voltage, and ambient temperature. It's recommended to check the device's thermal performance and power dissipation to ensure reliable operation.
The TPS25762CQRQLRQ1 has a built-in overcurrent protection feature that can be enabled by connecting the OCSET pin to a resistor divider network. The resistor values can be calculated based on the desired overcurrent threshold and the internal current sense resistor.
The EN (Enable) pin on the TPS25762CQRQLRQ1 is used to enable or disable the device. When the EN pin is high, the device is enabled, and when it's low, the device is disabled. The EN pin can be connected to a logic signal or a switch to control the device's operation.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS25762CQRQLRQ1 Overview
Use the download button to access the TPS25762CQRQLRQ1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS25,
or try a keyword search, such as Power Management Circuits
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
