A good PCB layout for the TPS26630RGET involves placing the input capacitors close to the VIN pin, using a solid ground plane, and keeping the high-current paths short and wide. A 4-layer PCB with a dedicated power plane is recommended.
When selecting an inductor for the TPS26630RGET, consider the inductor's saturation current, DC resistance, and core material. A good starting point is to choose an inductor with a saturation current rating of at least 1.5 times the maximum output current, and a DC resistance of less than 100 mΩ.
The TPS26630RGET is rated for operation from -40°C to 125°C, but the maximum ambient temperature range depends on the specific application and the device's power dissipation. In general, the device can operate up to 85°C ambient temperature with proper heat sinking and airflow.
To troubleshoot issues with the TPS26630RGET, start by checking the input voltage, output voltage, and current. Verify that the input capacitors are properly sized and placed, and that the inductor is suitable for the application. Check for thermal issues by measuring the device's temperature and ensuring proper heat sinking and airflow.
Yes, the TPS26630RGET is qualified for automotive and high-reliability applications. It meets the requirements of the AEC-Q100 standard for automotive applications, and is suitable for use in harsh environments.
