Texas Instruments provides a recommended PCB layout in the TPS48000QDGXRQ1 datasheet, but it's essential to follow additional guidelines for optimal thermal performance. Ensure a solid ground plane, use thermal vias, and keep the device away from heat sources. Refer to TI's Power Management Layout Guidelines for more information.
The output capacitor selection depends on the output voltage, current, and ripple requirements. TI recommends using a low-ESR capacitor with a minimum capacitance of 10uF. Use the TPS48000QDGXRQ1's output capacitor selection guide in the datasheet or TI's Capacitor Selection Tool to determine the optimal capacitor for your design.
Although the datasheet specifies a maximum input voltage of 5.5V, it's essential to consider the maximum voltage rating of the internal regulator, which is 6.5V. However, TI recommends operating the device within the specified input voltage range to ensure reliable operation and minimize the risk of damage.
The TPS48000QDGXRQ1 does not have a built-in OVP feature. To implement OVP, you can use an external voltage supervisor or a dedicated OVP IC. TI provides application notes and reference designs that demonstrate OVP implementation using external components.
The TPS48000QDGXRQ1 has a built-in short-circuit protection feature that limits the output current to prevent damage. During a short-circuit event, the device will enter a hiccup mode, where it will repeatedly attempt to restart and regulate the output voltage. This behavior helps prevent damage to the device and surrounding components.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS48000QDGXRQ1 Overview
Use the download button to access the TPS48000QDGXRQ1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS48,
or try a keyword search, such as Power Management Circuits
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
