A good PCB layout for the TPS48110AQDGXRQ1 should follow the guidelines provided in the datasheet, including keeping the input and output capacitors close to the device, using a solid ground plane, and minimizing the length of the input and output traces. Additionally, it is recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane to reduce EMI.
The choice of input and output capacitors for the TPS48110AQDGXRQ1 depends on the specific application requirements. In general, it is recommended to use low-ESR capacitors with a high ripple current rating. The input capacitor should be able to handle the input voltage and current, while the output capacitor should be able to handle the output voltage and current. A good starting point is to use a 10uF ceramic capacitor for the input and a 22uF ceramic capacitor for the output.
The TPS48110AQDGXRQ1 is rated for operation over a temperature range of -40°C to 125°C. However, the device may not be able to deliver its full performance over the entire temperature range. It is recommended to consult the datasheet and application notes for more information on temperature-related performance limitations.
Proper thermal management is critical for the reliable operation of the TPS48110AQDGXRQ1. This can be achieved by providing a good thermal path from the device to a heat sink or the PCB, using thermal interface materials, and ensuring good airflow around the device. The maximum junction temperature of the device is 150°C, and it is recommended to keep the junction temperature below 125°C for reliable operation.
When using the TPS48110AQDGXRQ1, it is important to consider EMI filtering to ensure compliance with regulatory requirements. This can be achieved by using a pi-filter or a common-mode choke on the input and output lines, and by following good PCB layout practices to minimize radiation. Additionally, it is recommended to use a shielded enclosure and to follow good cable management practices to minimize EMI radiation.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS48110AQDGXRQ1 Overview
Use the download button to access the TPS48110AQDGXRQ1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS48,
or try a keyword search, such as Power Management Circuits
