The maximum input voltage that can be applied to the TPS54262QPWPRQ1 is 60V, but it's recommended to operate within the specified input voltage range of 4.5V to 60V for optimal performance and reliability.
To ensure the stability of the output voltage, it's essential to follow the recommended layout and component selection guidelines, including the use of a suitable output capacitor and a low-ESR input capacitor. Additionally, the output voltage can be adjusted using the FB pin, and the output voltage stability can be improved by adding a capacitor in parallel with the output capacitor.
The maximum output current that the TPS54262QPWPRQ1 can deliver is 2A, but it's recommended to operate within the specified output current range of 0A to 2A for optimal performance and reliability.
The TPS54262QPWPRQ1 has built-in overcurrent protection (OCP) and thermal shutdown (TSD) features to protect the device from overcurrent and overheating. The OCP threshold is typically set to 2.5A, and the TSD threshold is typically set to 150°C. Additionally, it's recommended to use external protection components, such as fuses or PTC thermistors, to provide additional protection against overcurrent and overheating.
The typical efficiency of the TPS54262QPWPRQ1 is around 95% at a 12V input and 3.3V output, but it can vary depending on the input voltage, output voltage, and output current. The efficiency can be improved by optimizing the component selection and layout.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
TPS54262QPWPRQ1 Overview
Use the download button to access the TPS54262QPWPRQ1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS54,
or try a keyword search, such as Switching Regulator or Controllers
