The maximum input voltage that can be applied to the TPS54560BQDDAQ1 is 42V, but it's recommended to operate within the specified input voltage range of 6.5V to 36V for optimal performance.
To ensure the stability of the output voltage, it's essential to follow the recommended layout guidelines, use a suitable output capacitor, and ensure that the input voltage is within the specified range. Additionally, the output voltage can be adjusted using the FB pin, and the output voltage tolerance can be improved by using a voltage reference IC.
The maximum output current that the TPS54560BQDDAQ1 can deliver is 5A, but it's recommended to operate within the specified output current range of 0.5A to 4A for optimal performance and to prevent overheating.
To protect the TPS54560BQDDAQ1 from overheating, ensure that the device is operated within the specified temperature range of -40°C to 125°C, and that the thermal pad is properly connected to a heat sink or a thermal pad. Additionally, the device should be operated within the specified output current range, and the input voltage should be within the specified range.
The EN (enable) pin is used to enable or disable the device. When the EN pin is pulled high, the device is enabled, and when it's pulled low, the device is disabled. This pin can be used to implement power sequencing or to turn the device on and off.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS54560BQDDAQ1 Overview
Use the download button to access the TPS54560BQDDAQ1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS54,
or try a keyword search, such as Switching Regulator or Controllers
