Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good thermal design practices, such as using a solid ground plane, placing thermal vias under the IC, and keeping the PCB layer stack-up symmetrical.
To ensure accurate and stable output voltage, it's crucial to follow the recommended input and output capacitor selection, use a low-ESR output capacitor, and ensure the feedback network is properly designed and connected.
Although the datasheet specifies a maximum input voltage of 18V, it's recommended to derate the input voltage to 15V to ensure reliable operation and prevent damage to the device.
The TPS551892QWRYQRQ1 is rated for operation up to 125°C, but it's essential to consider the device's power dissipation, thermal resistance, and PCB design to ensure reliable operation in high-temperature environments.
To troubleshoot issues, start by verifying the PCB layout, input and output capacitor selection, and feedback network design. Use oscilloscopes and other diagnostic tools to identify the root cause of the issue, and consult the datasheet and application notes for guidance.
