The recommended layout and placement for the TPS65070RSLR involves placing the device close to the battery, using a solid ground plane, and keeping the input and output capacitors close to the device. A 4-layer PCB with a solid ground plane is recommended. Refer to the TI application note 'TPS65070RSLR Layout and Placement Guidelines' for more information.
To optimize the TPS65070RSLR for low quiescent current, ensure that the EN pin is driven high or low correctly, use a low-IQ mode, and minimize the number of active regulators. Additionally, use a low-dropout linear regulator (LDO) for the always-on domain, and consider using a low-power mode for the device.
The TPS65070RSLR has a thermal pad that must be connected to a solid ground plane to ensure proper heat dissipation. The device can operate up to 105°C, but the junction temperature should be kept below 125°C. A thermal analysis should be performed to ensure the device operates within the recommended temperature range.
To troubleshoot issues with the TPS65070RSLR, start by checking the input voltage, output voltage, and enable pin. Verify that the device is properly configured and that the input and output capacitors are correctly sized. Use an oscilloscope to check for voltage rails, and consult the TI troubleshooting guide for the TPS65070RSLR.
The TPS65070RSLR is designed to meet EMI and EMC standards, but proper PCB layout and design are crucial to minimize emissions. Use a solid ground plane, keep the input and output capacitors close to the device, and consider using EMI filters or shielding to minimize emissions.
