The maximum input voltage that can be applied to the TPS7350QDRG4 is 12V, but it's recommended to keep it below 10V to ensure reliable operation and to prevent damage to the internal voltage regulator.
To ensure stability, it's essential to follow the recommended layout and component selection guidelines provided in the datasheet. This includes using a 2.2uF or larger output capacitor, a 1uF or larger input capacitor, and keeping the input and output capacitors close to the device. Additionally, ensure that the PCB layout is well-designed and doesn't introduce any parasitic inductance or capacitance that could cause oscillation.
The TPS7350QDRG4 is rated for operation up to 125°C, but its performance and reliability may degrade at higher temperatures. It's essential to consider the thermal design and ensure that the device is properly heat-sinked and that the ambient temperature is within the recommended operating range.
The power dissipation of the TPS7350QDRG4 can be calculated using the formula: Pd = (Vin - Vout) x Iout, where Vin is the input voltage, Vout is the output voltage, and Iout is the output current. Additionally, you should also consider the quiescent current (Iq) and the power consumed by the device during shutdown (Pshutdown).
Yes, the TPS7350QDRG4 can be used in an LDO configuration, but it's essential to ensure that the input voltage is within the recommended range and that the output voltage is set correctly. The device has a low dropout voltage of around 300mV, making it suitable for LDO applications.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS7350QDRG4 Overview
Use the download button to access the TPS7350QDRG4 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS73,
or try a keyword search, such as Linear Regulator ICs
