A good PCB layout for the TPSM63606RDLR involves placing the input capacitors close to the VIN pin, using a solid ground plane, and keeping the high-current paths short and wide. TI provides a recommended PCB layout in the datasheet and application notes.
Select an inductor with a high saturation current rating, low DC resistance, and a suitable inductance value based on the switching frequency and output voltage. TI provides inductor selection guidelines in the datasheet and application notes.
The TPSM63606RDLR is rated for operation from -40°C to 125°C ambient temperature. However, the device's performance and reliability may degrade at extreme temperatures.
Yes, the TPSM63606RDLR is AEC-Q100 qualified and suitable for high-reliability and automotive applications. However, additional testing and validation may be required to ensure compliance with specific industry standards.
Use an oscilloscope to monitor the output voltage, input voltage, and switching node waveforms. Check for proper PCB layout, component selection, and thermal design. Consult the datasheet, application notes, and TI's support resources for troubleshooting guidance.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPSM63606RDLR Overview
Use the download button to access the TPSM63606RDLR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPSM6,
or try a keyword search, such as Switching Regulator or Controllers
