Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good high-frequency design practices, such as using a solid ground plane, minimizing trace lengths, and avoiding vias under the device.
Use a low-ESR capacitor (e.g., 0.1 μF) as close as possible to the VCC pin, and a larger capacitor (e.g., 10 μF) in parallel to filter out noise. Ensure the power supply can provide the required current, and consider using a voltage regulator if necessary.
The TS3V712ELRTGR is specified to support data rates up to 4 Gbps, but the actual achievable data rate depends on the system design, PCB layout, and signal integrity. In practice, engineers have reported achieving data rates up to 3.2 Gbps.
To enter power-down mode, assert the EN pin low. During power-down, the device's outputs are high-impedance, and the supply current is reduced. Ensure that the EN pin is properly driven and that the device is not in a state where it can be damaged by backdrive or other external factors.
The TS3V712ELRTGR has a maximum junction temperature of 150°C. Ensure good thermal design practices, such as providing adequate heat sinking, using thermal vias, and keeping the device away from heat sources. Monitor the device's temperature and adjust the system design accordingly.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TS3V712ELRTGR Overview
Use the download button to access the TS3V712ELRTGR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TS3V7,
or try a keyword search, such as Multiplexers or Switches
