UCC21750QDWRQ1 - Texas Instruments

Description: Gate Drivers Automotive, single channel isolated gate driver for SiC/IGBT with advanced protection and high-CMTI 16-SOIC -40 to 125

Download UCC21750QDWRQ1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
UCC21750QDWRQ1 - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - DW (R-PDSO-G16)
click to zoom
3D Models
UCC21750QDWRQ1 - Texas Instruments  - 3D model - Small Outline Packages - DW (R-PDSO-G16)
click to zoom

UCC21750QDWRQ1 Details

  • Manufacturer Part Number:

    UCC21750QDWRQ1

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Malaysia, Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Date Of Intro:

    2019-10-03

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Additional Feature:

    NEG SUPPLY-NOM AT O/P SIDE IS -5V

  • High Side Driver:

    YES

  • Input Characteristics:

    DIFFERENTIAL

  • Interface IC Type:

    BUFFER OR INVERTER BASED IGBT/MOSFET DRIVER

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e4

  • Length:

    10.3 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Characteristics:

    STANDARD

  • Output Current-Max:

    10 A

  • Output Peak Current Limit-Nom:

    10 A

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    2.65 mm

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    3 V

  • Supply Voltage-Nom:

    3.3 V

  • Supply Voltage1-Max:

    33 V

  • Supply Voltage1-Min:

    13 V

  • Supply Voltage1-Nom:

    15 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Turn-off Time:

    0.13 µs

  • Turn-on Time:

    0.13 µs

  • Width:

    7.5 mm

UCC21750QDWRQ1 Frequently Asked Questions (FAQs)

  • A good PCB layout for the UCC21750QDWRQ1 involves keeping the high-frequency switching nodes (e.g., SW and VIN) away from sensitive analog nodes, using a solid ground plane, and minimizing the length of the traces connected to the IC's pins. TI provides a recommended PCB layout in the datasheet and application notes.
  • To ensure the UCC21750QDWRQ1 operates within its SOA, monitor the IC's junction temperature (TJ) and ensure it stays below the maximum rated value (150°C). Also, keep the input voltage (VIN) and output voltage (VOUT) within the recommended operating ranges, and avoid exceeding the maximum current ratings.
  • When selecting external components for the UCC21750QDWRQ1, consider the operating frequency, output voltage, and current requirements. Choose inductors with low DC resistance and high saturation current, and capacitors with low ESR and high ripple current ratings. TI provides guidance on component selection in the datasheet and application notes.
  • To troubleshoot issues with the UCC21750QDWRQ1, start by verifying the PCB layout and component selection. Check for proper decoupling, filtering, and grounding. Use an oscilloscope to monitor the IC's pins and identify any unusual waveforms or oscillations. Consult the datasheet, application notes, and TI's support resources for guidance on troubleshooting and debugging.
  • To manage the thermal performance of the UCC21750QDWRQ1, ensure good airflow around the IC, and consider using a heat sink or thermal interface material (TIM) to improve heat dissipation. Monitor the IC's junction temperature (TJ) and ensure it stays within the recommended operating range.
