Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep the high-frequency components (such as the transformer and the power MOSFETs) close to the IC. Additionally, it is recommended to use a shielded inductor and to keep the output voltage sense lines away from the high-current paths.
The compensation network can be optimized by using the TI's Power Stage Designer tool, which provides a graphical user interface to design and optimize the compensation network. Additionally, the datasheet provides a step-by-step procedure to design the compensation network manually.
The maximum junction temperature that the UCC28780RTER can withstand is 150°C. However, it is recommended to keep the junction temperature below 125°C for reliable operation.
No, the UCC28780RTER is designed for isolated topologies such as flyback, forward, and half-bridge converters. It is not suitable for non-isolated topologies such as buck or boost converters.
First, check the input voltage and current to ensure they are within the recommended range. Then, check the output voltage and current to ensure they are within the expected range. If the issue persists, check the compensation network and the transformer design. Finally, use an oscilloscope to check the waveforms at the input and output of the converter.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
UCC28780RTER Overview
Use the download button to access the UCC28780RTER schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like UCC28,
or try a keyword search, such as Switching Regulator or Controllers
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
