UWP1E100MCL1GB - Nichicon

UWP1E100MCL1GB Details

• Manufacturer Part Number:

  UWP1E100MCL1GB

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Not Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00

• Manufacturer:

  Nichicon Corporation

• YTEOL:

  6.95

• Capacitance:

  10 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  6.3 mm

• Dielectric Material:

  ALUMINUM (WET)

• Height:

  5.4 mm

• JESD-609 Code:

  e6

• Leakage Current:

  0.0125 mA

• Length:

  6.6 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR, 15 INCH

• Polarity:

  NON-POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  25 V

• Reference Standard:

  AEC-Q200

• Ripple Current:

  27 mA

• Size Code:

  2626

• Surface Mount:

  YES

• Tan Delta:

  0.17

• Terminal Finish:

  Tin/Bismuth (Sn/Bi)

• Terminal Shape:

  FLAT

• Width:

  6.6 mm
