VN920DSP - STMicroelectronics

Description: Single channel high side solid state relay, 5.5V to 36 V, 45 A 500 mA, 200 µs, - 40 °C to 150 °C

Download VN920DSP Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
VN920DSP - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
VN920DSP - STMicroelectronics PCB footprint - Other - Other - PowerSO-10_2026-1.1
click to zoom

VN920DSP Details

  • Manufacturer Part Number:

    VN920DSP

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    SOIC

  • Package Description:

    POWER, SO-10

  • Pin Count:

    10

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    0

  • Built-in Protections:

    TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE

  • Driver Number of Bits:

    1

  • Interface IC Type:

    BUFFER OR INVERTER BASED PERIPHERAL DRIVER

  • JESD-30 Code:

    R-PDSO-G10

  • JESD-609 Code:

    e3

  • Length:

    9.4 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    10

  • Output Current Flow Direction:

    SINK

  • Output Current-Max:

    25 A

  • Output Peak Current Limit-Nom:

    45 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP10,.55FL

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    250

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    3.65 mm

  • Supply Voltage-Max:

    36 V

  • Supply Voltage-Min:

    5.5 V

  • Supply Voltage-Nom:

    13 V

  • Surface Mount:

    YES

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    7.5 mm

VN920DSP Frequently Asked Questions (FAQs)

  • STMicroelectronics provides a recommended PCB layout in the application note AN5333, which includes guidelines for component placement, routing, and thermal management to ensure optimal performance and minimize electromagnetic interference (EMI).
  • The VN920DSP is a highly configurable device that can be programmed to support various automotive bus protocols such as CAN, LIN, and SAE J1939. The configuration is done through the SPI interface using a dedicated software development kit (SDK) provided by STMicroelectronics.
  • The VN920DSP is rated for operation in the -40°C to 125°C temperature range, making it suitable for use in harsh automotive environments. However, the device's performance and reliability may be affected at extreme temperatures, so it's essential to follow the recommended operating conditions and thermal management guidelines.
  • Yes, the VN920DSP is designed to meet the requirements of safety-critical applications in the automotive industry. It has been developed according to the ISO 26262 functional safety standard and is ASIL-D compliant. However, it's essential to follow the recommended design and verification guidelines to ensure the device meets the specific safety requirements of the application.
  • STMicroelectronics provides a range of tools and resources to help troubleshoot issues with the VN920DSP, including a dedicated evaluation board, software development kits, and application notes. Additionally, the device has built-in diagnostic capabilities, such as error detection and reporting, to help identify and debug issues.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

VN920DSP Overview

Use the download button to access the VN920DSP schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like VN920, or try a keyword search, such as Peripheral Drivers

About STMicroelectronics

STMicroelectronics (ST) is a global semiconductor company that designs, manufactures, and markets a broad range of integrated circuits (ICs), discrete devices, and other electronic components. STMicroelectronics offers a diverse portfolio of semiconductor products covering a wide range of applications and industries. Their product categories include microcontrollers, analog and mixed-signal ICs, MEMS (Micro-Electro-Mechanical Systems) sensors, power management ICs, RF (Radio Frequency) transceivers, aut
