W979H6KBVX2I - Winbond

Description: VFBGA134

Download W979H6KBVX2I Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
W979H6KBVX2I - Winbond PCB footprint - BGA - BGA - VFBGA 134 Ball (10x11.5 mm2, Ball pitch: 0.65mm, Ø =0.40mm)
click to zoom
3D Models
W979H6KBVX2I - Winbond  - 3D model - BGA - VFBGA 134 Ball (10x11.5 mm2, Ball pitch: 0.65mm, Ø =0.40mm)
click to zoom

W979H6KBVX2I Details

  • Manufacturer Part Number:

    W979H6KBVX2I

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Package Description:

    VFBGA-134

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.32.00.28

  • Manufacturer:

    Winbond Electronics Corp

  • YTEOL:

    3

  • Access Mode:

    FOUR BANK PAGE BURST

  • Additional Feature:

    AUTO/SELF REFRESH; IT ALSO REQUIRES 1.8V NOM

  • JESD-30 Code:

    R-PBGA-B134

  • Length:

    11.5 mm

  • Memory Density:

    536870912 bit

  • Memory IC Type:

    LPDDR2 DRAM

  • Memory Width:

    16

  • Number of Functions:

    1

  • Number of Ports:

    1

  • Number of Terminals:

    134

  • Number of Words:

    33554432 words

  • Number of Words Code:

    32000000

  • Operating Mode:

    SYNCHRONOUS

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Organization:

    32MX16

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VFBGA

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Seated Height-Max:

    1 mm

  • Self Refresh:

    YES

  • Supply Voltage-Max (Vsup):

    1.3 V

  • Supply Voltage-Min (Vsup):

    1.14 V

  • Supply Voltage-Nom (Vsup):

    1.2 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    10 mm
