W989D2DBJX6I - Winbond

Description: 512Mb Low Power SDR SDRAM 166MHz VFBGA90 1.8V/1.8V

Download W989D2DBJX6I Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
W989D2DBJX6I - Winbond PCB footprint - BGA - BGA - VFBGA 90 Balls (8x13 mm2 , Ball pitch: 0.8mm)-1
click to zoom
3D Models
W989D2DBJX6I - Winbond  - 3D model - BGA - VFBGA 90 Balls (8x13 mm2 , Ball pitch: 0.8mm)-1
click to zoom

W989D2DBJX6I Details

  • Manufacturer Part Number:

    W989D2DBJX6I

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    VFBGA-90

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.32.00.28

  • Manufacturer:

    Winbond Electronics Corp

  • YTEOL:

    4

  • Access Mode:

    FOUR BANK PAGE BURST

  • Access Time-Max:

    5 ns

  • Additional Feature:

    AUTO/SELF REFRESH

  • JESD-30 Code:

    R-PBGA-B90

  • Length:

    13 mm

  • Memory Density:

    536870912 bit

  • Memory IC Type:

    SYNCHRONOUS DRAM

  • Memory Width:

    32

  • Number of Functions:

    1

  • Number of Ports:

    1

  • Number of Terminals:

    90

  • Number of Words:

    16777216 words

  • Number of Words Code:

    16000000

  • Operating Mode:

    SYNCHRONOUS

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Organization:

    16MX32

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TFBGA

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Seated Height-Max:

    1.025 mm

  • Self Refresh:

    YES

  • Supply Voltage-Max (Vsup):

    1.95 V

  • Supply Voltage-Min (Vsup):

    1.7 V

  • Supply Voltage-Nom (Vsup):

    1.8 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.8 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    8 mm

W989D2DBJX6I Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the W989D2DBJX6I is 2.7V to 3.6V.
  • The W989D2DBJX6I has an internal POR circuit that ensures the device is in a reset state during power-up. No external reset circuitry is required.
  • The W989D2DBJX6I supports a maximum clock frequency of 104 MHz.
  • The W989D2DBJX6I has a built-in write protection mechanism that can be enabled through software commands. Additionally, external write protection can be implemented using external circuitry or software-based methods.
  • The typical standby current consumption of the W989D2DBJX6I is around 10 μA.
