XC6810B43H0R-G - Torex

Description: Linear Charger IC for Li-ion battery With Ultra-small Package Compatible With Wireless Charging

Download XC6810B43H0R-G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
XC6810B43H0R-G - Torex PCB footprint - BGA - BGA - WLP-12-01
click to zoom
3D Models
XC6810B43H0R-G - Torex  - 3D model - BGA - WLP-12-01
click to zoom

XC6810B43H0R-G Details

  • Manufacturer Part Number:

    XC6810B43H0R-G

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Japan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Torex Semiconductor LTD

  • YTEOL:

    10

  • Analog IC - Other Type:

    LINEAR BATTERY CHARGER

XC6810B43H0R-G Frequently Asked Questions (FAQs)

  • Torex recommends a 4-layer PCB with a solid ground plane and a separate power plane for the input and output. The input and output capacitors should be placed as close as possible to the IC, and the feedback resistors should be placed close to the output pin. A detailed layout guide can be found in the Torex application note AN-104.
  • To ensure stability, it's essential to follow the recommended component values and PCB layout. Additionally, the output capacitor should be selected based on the ESR (Equivalent Series Resistance) and the output voltage ripple requirements. A minimum output capacitance of 10uF is recommended, and the ESR should be less than 100mΩ. The input capacitor should be selected based on the input voltage ripple requirements and the maximum input current.
  • The maximum ambient temperature for the XC6810B43H0R-G is 85°C. However, the device can operate up to 105°C with derating. It's essential to follow the thermal design guidelines and ensure proper heat dissipation to prevent overheating.
  • Yes, the XC6810B43H0R-G is designed to operate in high-vibration environments. However, it's essential to follow the recommended PCB mounting and soldering guidelines to ensure the device is securely attached to the PCB. Additionally, the PCB should be designed to withstand the vibration and shock requirements of the application.
  • Torex recommends using a low-ESR ceramic capacitor or a film capacitor with a minimum capacitance of 1uF and a maximum ESR of 100mΩ. The input capacitor should be selected based on the input voltage ripple requirements and the maximum input current.
