XLH736002.048000I - Renesas Electronics

XLH736002.048000I Details

• Manufacturer Part Number:

  XLH736002.048000I

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CLCC, 6 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  6

• Additional Feature:

  ENABLE/DISABLE FUNCTION; ALSO COMPATIBLE WITH LVCMOS OUTPUT

• Fall Time-Max:

  3 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  2.048 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCMOS

• Output Load:

  15 pF

• Physical Dimension:

  7.0mm x 5.0mm x 1.3mm

• Rise Time-Max:

  3 ns

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
