XTR111AIDRCTG4 - Texas Instruments

Description: Sensor Interface Presision Voltage to Current Conv/Trans

Download XTR111AIDRCTG4 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
XTR111AIDRCTG4 - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
XTR111AIDRCTG4 - Texas Instruments PCB footprint - Other - Other - DRC (S-PVSON-N10)
click to zoom
3D Models
XTR111AIDRCTG4 - Texas Instruments - 3D model - Other - DRC (S-PVSON-N10)
click to zoom

XTR111AIDRCTG4 Details

  • Manufacturer Part Number:

    XTR111AIDRCTG4

  • Brand Name:

    Texas Instruments

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    SON

  • Package Description:

    SON-10

  • Pin Count:

    10

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    0

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-PDSO-N10

  • JESD-609 Code:

    e4

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    10

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Equivalence Code:

    SOLCC10,.12,20

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1 mm

  • Supply Current-Max (Isup):

    0.55 mA

  • Supply Voltage-Max (Vsup):

    44 V

  • Supply Voltage-Min (Vsup):

    7 V

  • Supply Voltage-Nom (Vsup):

    24 V

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Temperature Grade:

    MILITARY

  • Terminal Finish:

    NICKEL PALLADIUM GOLD

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

XTR111AIDRCTG4 Frequently Asked Questions (FAQs)

  • Texas Instruments provides a recommended PCB layout in the XTR111AIDRCTG4 datasheet (Section 10.1) and in the XTR111AIDRCTG4 Evaluation Module User's Guide. It's essential to follow these guidelines to minimize noise, ensure proper thermal management, and optimize signal integrity.
  • The XTR111AIDRCTG4 has a programmable output voltage range. You can configure it using the VOUT_MODE pin (Pin 14) and the VOUT_TRIM pin (Pin 15). Refer to the datasheet (Section 7.3.5) for the specific configuration options and equations to calculate the desired output voltage.
  • The XTR111AIDRCTG4 has an absolute maximum input voltage rating of 42V. However, the recommended operating input voltage range is 4.5V to 38V. Exceeding the absolute maximum rating can damage the device.
  • To ensure a stable operating condition during startup, make sure to follow the recommended power-up sequence (Section 10.2 of the datasheet). This includes applying the input voltage before enabling the device, and allowing the internal voltage regulators to stabilize before enabling the output.
  • The thermal derating curve for the XTR111AIDRCTG4 is provided in the datasheet (Section 6.3). It shows the maximum output current vs. ambient temperature. You can use this curve to determine the maximum output current at a given temperature.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

XTR111AIDRCTG4 Overview

Use the download button to access the XTR111AIDRCTG4 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like XTR11, or try a keyword search, such as Other Signal Circuits

About Texas Instruments

Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
