ZXMN2B14FH - Diodes Incorporated

ZXMN2B14FH Details

• Manufacturer Part Number:

  ZXMN2B14FH

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOT-23

• Package Description:

  SOT-23, 3 PIN

• Pin Count:

  3

• ECCN Code:

  EAR99

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  6.95

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  20 V

• Drain Current-Max (ID):

  0.0043 A

• Drain-source On Resistance-Max:

  0.055 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  90 pF

• JESD-30 Code:

  R-PDSO-G3

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
