Texas Instruments provides a layout and routing guide for the ADS7863ARGET in the 'ADS7863 Layout and Routing Guidelines' application note (SLAA744). It recommends a 4-layer PCB with a solid ground plane, and provides guidance on component placement, routing, and decoupling.
The ADS7863ARGET does not require calibration in the classical sense. However, it does require a system-level calibration to remove gain and offset errors. This can be done by applying a known input voltage and measuring the output code, and then using this data to calculate the gain and offset correction factors.
The maximum sampling rate of the ADS7863ARGET is 250 kSPS. However, this rate can be affected by the clock frequency, conversion mode, and other system-level factors. It's recommended to consult the datasheet and application notes for more information on achieving the highest possible sampling rate.
Yes, the ADS7863ARGET can be used in a multiplexed configuration. However, this requires additional external circuitry to multiplex the input signals and control the conversion process. Texas Instruments provides an example of a multiplexed configuration in the 'ADS7863 Multiplexed Configuration' application note (SLAA745).
The ADS7863ARGET outputs 16-bit digital data in a serial format. This data can be handled using a microcontroller or FPGA, which can perform tasks such as data processing, filtering, and storage. It's recommended to consult the datasheet and application notes for more information on handling the digital output data.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS7863ARGET Overview
Use the download button to access the ADS7863ARGET schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS78,
or try a keyword search, such as Analog to Digital Converters
