The recommended layout and routing for the ADS7951SRGER involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the analog input traces. It's also recommended to use a 4-layer PCB with a dedicated analog power plane and a dedicated digital power plane.
To optimize the performance of the ADS7951SRGER in noisy environments, use a low-pass filter at the input, use a shielded cable for the analog input, and consider using a common-mode filter. Additionally, ensure that the analog and digital grounds are properly separated and that the power supply is well-regulated.
The maximum sampling rate of the ADS7951SRGER is 1.5 MSPS (mega-samples per second). However, the actual sampling rate may be limited by the system's clock frequency, the analog input bandwidth, and the digital interface.
The ADS7951SRGER does not require calibration. However, it's recommended to perform a system-level calibration to ensure that the ADC is operating within the specified accuracy. This can be done by applying a known input voltage and measuring the output code.
The power consumption of the ADS7951SRGER is typically around 35 mW at 1.5 MSPS, with a 3.3V analog supply and a 1.8V digital supply. However, the actual power consumption may vary depending on the system's clock frequency, the analog input bandwidth, and the digital interface.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
ADS7951SRGER Overview
Use the download button to access the ADS7951SRGER schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS79,
or try a keyword search, such as Analog to Digital Converters
