Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep the analog and digital signals separate. The analog input traces should be short and direct, and the digital output traces should be routed away from the analog inputs. Additionally, decoupling capacitors should be placed close to the device.
The ADS7953SRHBT has an internal calibration circuit that is enabled by default. However, for optimal performance, it is recommended to perform an external calibration using an external voltage reference and a calibration resistor. The calibration procedure is outlined in the datasheet.
The maximum sampling rate of the ADS7953SRHBT is 2 MSPS. However, the actual sampling rate may be limited by the system's clock frequency, the analog input bandwidth, and the digital output data rate. Additionally, the device's power consumption and thermal performance may also impact the maximum achievable sampling rate.
The ADS7953SRHBT outputs 16-bit digital data in a serial format. The output data is in two's complement format, with the most significant bit (MSB) first. The device also provides a data ready signal (DRDY) to indicate when the conversion is complete and the data is ready to be read.
The ADS7953SRHBT has a typical power consumption of 15 mW at 2 MSPS. To minimize power consumption, it is recommended to use the device's power-down mode when not in use, and to optimize the system's clock frequency and analog input bandwidth to reduce power consumption.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
ADS7953SRHBT Overview
Use the download button to access the ADS7953SRHBT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS79,
or try a keyword search, such as Analog to Digital Converters
