Texas Instruments provides a layout guide and PCB design checklist in the ADS8326IDRBR datasheet and application notes. It's essential to follow these guidelines to ensure proper operation and minimize noise and interference. Key considerations include keeping analog and digital signals separate, using a solid ground plane, and placing decoupling capacitors close to the device.
The ADS8326IDRBR has high-speed digital outputs that require careful handling to prevent signal degradation and electromagnetic interference (EMI). Use transmission lines, such as 50-ohm microstrip or stripline, to route the digital outputs, and terminate them with a 50-ohm load. Additionally, use a low-inductance path for the digital output signals and avoid vias and right-angle turns.
The ADS8326IDRBR has a high-impedance analog input, so it's essential to filter the input signals to prevent noise and aliasing. Use a low-pass filter, such as a 2nd-order Butterworth or Chebyshev filter, with a cutoff frequency below the Nyquist frequency (half the sampling rate). Place the filter close to the analog input pins and use a low-noise, high-precision op-amp, such as the OPA211 or OPA827.
The ADS8326IDRBR requires accurate timing and synchronization to ensure proper operation. Use a high-quality clock source, such as a crystal oscillator or a low-jitter clock generator, and ensure that the clock signal is properly terminated and routed. Additionally, use a synchronization signal, such as a frame sync or a clock enable signal, to synchronize the ADC with the system clock.
The ADS8326IDRBR requires a stable and noise-free power supply to ensure accurate operation. Use a low-noise, high-PSRR power supply, such as a linear regulator or a switching regulator with a low-noise output filter. Decouple the power supply pins with a combination of ceramic and electrolytic capacitors, and place them close to the device. Use a separate power plane for the analog and digital supplies to minimize noise coupling.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
ADS8326IDRBR Overview
Use the download button to access the ADS8326IDRBR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS83,
or try a keyword search, such as Analog to Digital Converters
