Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep the analog and digital signals separate. The datasheet provides a recommended layout and routing guide, but it's also recommended to consult with a TI FAE or a PCB design expert for specific guidance.
To optimize performance in noisy environments, use a low-pass filter on the input, keep the analog and digital grounds separate, and use a shielded cable for the analog input. Additionally, consider using a common-mode filter or a differential amplifier to reject common-mode noise.
The maximum sampling rate of the ADS8353IRTET is 250 kSPS, but this can be affected by the system clock frequency, the input signal frequency, and the desired signal-to-noise ratio. Consult the datasheet and application notes for more information.
Calibration involves adjusting the offset and gain of the ADC to match the specific application requirements. TI provides a calibration procedure in the datasheet and application notes, which involves applying a known input signal and adjusting the offset and gain registers accordingly.
The power consumption of the ADS8353IRTET is typically around 15 mW at 250 kSPS, but this can be reduced by using the power-down mode, reducing the clock frequency, or using the low-power mode. Consult the datasheet for more information on power management.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS8353IRTET Overview
Use the download button to access the ADS8353IRTET schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS83,
or try a keyword search, such as Analog to Digital Converters
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
