Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep the analog and digital signals separate. The datasheet provides a recommended layout and routing guide, but it's also recommended to consult with a TI FAE or a PCB design expert for specific guidance.
Optimizing the performance of the ADS8678IDBT requires careful consideration of the system's noise budget, signal chain, and PCB layout. TI recommends using the ADS8678IDBT evaluation module (EVM) to evaluate the device's performance and to optimize the design. Additionally, TI's WEBENCH online design tool can be used to simulate and optimize the design.
The maximum sampling rate of the ADS8678IDBT is 250 kSPS, but this can be limited by the system's noise floor, signal bandwidth, and analog front-end design. TI recommends consulting the datasheet and application notes for specific guidance on achieving the maximum sampling rate.
The ADS8678IDBT has an internal calibration circuit that can be used to calibrate the device. TI recommends following the calibration procedure outlined in the datasheet and application notes. Additionally, the ADS8678IDBT EVM provides a calibration tool that can be used to simplify the calibration process.
The power consumption of the ADS8678IDBT is typically around 35 mW at 250 kSPS. To minimize power consumption, TI recommends using the device's power-down mode, reducing the sampling rate, and optimizing the system's power supply design. Additionally, the ADS8678IDBT has a low-power mode that can be used to reduce power consumption when the device is not in use.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS8678IDBT Overview
Use the download button to access the ADS8678IDBT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS86,
or try a keyword search, such as Analog to Digital Converters
