The recommended layout and routing for the ADS8678IDBTR involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the analog signal traces. It's also recommended to use a 4-layer PCB with a dedicated analog power plane and a dedicated digital power plane.
To optimize the performance of the ADS8678IDBTR in a noisy environment, use a low-pass filter at the input, use a shielded cable, and keep the analog signal traces away from the digital signal traces. Additionally, use a common-mode filter or a ferrite bead to filter out high-frequency noise.
The maximum sampling rate that can be achieved with the ADS8678IDBTR is 250 kSPS. However, the actual sampling rate may vary depending on the system clock frequency, the number of channels, and the conversion mode.
The ADS8678IDBTR has an internal calibration circuit that can be enabled by setting the CAL bit in the control register. The calibration process involves shorting the input pins to the internal reference voltage and then adjusting the offset and gain registers to achieve the desired accuracy.
The power consumption of the ADS8678IDBTR varies depending on the operating mode, sampling rate, and supply voltage. In normal operation, the typical power consumption is around 35 mW at 3.3 V supply voltage and 250 kSPS sampling rate.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ADS8678IDBTR Overview
Use the download button to access the ADS8678IDBTR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADS86,
or try a keyword search, such as Analog to Digital Converters
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
