AFK108M50P44T-F - Cornell Dubilier

AFK108M50P44T-F Details

• Manufacturer Part Number:

  AFK108M50P44T-F

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.20

• Manufacturer:

  Knowles CDE

• YTEOL:

  7

• Additional Feature:

  ESR IS MEASURED AT 100 KHZ

• Capacitance:

  1000 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  16 mm

• Dielectric Material:

  ALUMINUM (WET)

• ESR:

  73 mΩ

• Height:

  16.5 mm

• JESD-609 Code:

  e3

• Leakage Current:

  0.5 mA

• Length:

  19 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  50 V

• Reference Standard:

  AEC-Q200

• Ripple Current:

  1207.5 mA

• Size Code:

  7567

• Surface Mount:

  YES

• Tan Delta:

  0.1

• Terminal Finish:

  Tin (Sn)

• Terminal Shape:

  FLAT

• Width:

  17 mm
