- Part Number BQ2023PWR
- Manufacturer Texas Instruments
- Pin Count 8
- Part Category Integrated Circuit
- Package Category Small Outline Packages
- Footprint Name Small Outline Packages - PW0008A
- Released Date Apr 10, 2022
- Last Modified Date Nov 29, 2023 6:25 AM UTC
- Pinout / Pin List Click Here (Member Only)
BQ2023PWR Details
-
Manufacturer Part Number:
BQ2023PWR
-
Brand Name:
Texas Instruments
-
Pbfree Code:
Yes
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Part Package Code:
SOIC
-
Pin Count:
8
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.90
-
Manufacturer:
Texas Instruments
-
YTEOL:
1
BQ2023PWR Frequently Asked Questions (FAQs)
-
The recommended layout and placement for the BQ2023PWR involves keeping the device close to the battery, using a solid ground plane, and minimizing the distance between the device and the battery. It's also important to follow the recommended PCB layout guidelines provided in the datasheet and application notes.
-
Calibration of the BQ2023PWR involves adjusting the device's internal registers to match the specific battery characteristics. This can be done using the TI-provided software tools, such as the Battery Management Studio, and following the calibration procedure outlined in the datasheet and application notes.
-
Temperature can affect the BQ2023PWR's accuracy and performance. The device is designed to operate within a specific temperature range (-40°C to 85°C), and temperature compensation is built-in. However, it's essential to consider temperature effects when designing the system, especially in extreme temperature environments.
-
The BQ2023PWR has a sleep mode to reduce power consumption. To handle sleep mode and wake-up mechanisms, engineers should follow the recommended procedures outlined in the datasheet, including setting the sleep timer, using the wake-up pins, and ensuring proper system design to minimize power consumption during sleep mode.
-
The BQ2023PWR is designed to work with various battery chemistries, including Li-ion, NiMH, and Lead-Acid. However, engineers should consider the specific battery characteristics, such as voltage and capacity, when designing the system. Additionally, the device's internal registers may need to be adjusted to match the specific battery chemistry.
Trust Checks
Community Provided
System Verified
Community Approved
BQ2023PWR Overview
Use the download button to access the BQ2023PWR schematic symbol, PCB footprint, and 3D model.
