Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good PCB design practices, such as keeping the analog and digital grounds separate, using a solid ground plane, and minimizing noise coupling. Additionally, ensure that the input and output capacitors are placed close to the device.
The selection of input and output capacitors depends on the specific application requirements. Generally, X5R or X7R ceramic capacitors with a voltage rating of 10V or higher are recommended. The capacitance value should be at least 10uF for the input capacitor and 22uF for the output capacitor. It's also essential to consider the ESR (Equivalent Series Resistance) and ESL (Equivalent Series Inductance) of the capacitors.
The BQ78350DBT-R1 is rated for operation from -40°C to 125°C. However, the device's performance and reliability may degrade at extreme temperatures. It's essential to ensure that the device is operated within the recommended temperature range for optimal performance and reliability.
The BQ78350DBT-R1 has a specific power-up and power-down sequence. During power-up, the input voltage should be applied before the enable pin is asserted. During power-down, the enable pin should be de-asserted before the input voltage is removed. It's essential to follow this sequence to prevent damage to the device or other components in the system.
The recommended input voltage range for the BQ78350DBT-R1 is 2.7V to 5.5V. Operating the device outside this range may affect its performance, efficiency, and reliability.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BQ78350DBT-R1 Overview
Use the download button to access the BQ78350DBT-R1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BQ783,
or try a keyword search, such as Power Management Circuits
