DRV10983SQPWPRQ1 - Texas Instruments

Description: 30W, 12v Automotive 3-phase sensorless BLDC motor driver with load dump support

Download DRV10983SQPWPRQ1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DRV10983SQPWPRQ1 - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
DRV10983SQPWPRQ1 - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - DRV10983SQPWPRQ1_
click to zoom
3D Models
DRV10983SQPWPRQ1 - Texas Instruments - 3D model - Small Outline Packages - DRV10983SQPWPRQ1_
click to zoom

DRV10983SQPWPRQ1 Details

  • Manufacturer Part Number:

    DRV10983SQPWPRQ1

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Date Of Intro:

    2017-06-10

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Analog IC - Other Type:

    3-PHASE BRUSHLESS DC MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDSO-G24

  • JESD-609 Code:

    e4

  • Length:

    7.8 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max (Vsup):

    28 V

  • Supply Voltage-Min (Vsup):

    6.2 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4.4 mm

DRV10983SQPWPRQ1 Frequently Asked Questions (FAQs)

  • A good PCB layout for the DRV10983SQPWPRQ1 involves keeping the high-current paths short and wide, using a solid ground plane, and placing the device close to the motor. TI provides a recommended PCB layout in the datasheet and application notes.
  • The sense resistor (Rs) should be chosen based on the motor current and the desired current sense accuracy. A smaller Rs value provides better current sense accuracy but increases the power loss in the sense resistor. TI provides a formula to calculate the optimal Rs value in the datasheet.
  • The DRV10983SQPWPRQ1 has an operating temperature range of -40°C to 125°C. However, the device's performance and reliability may degrade at higher temperatures. It's essential to ensure proper thermal management and heat sinking to maintain a safe operating temperature.
  • The DRV10983SQPWPRQ1 has built-in overvoltage protection (OVP) and undervoltage protection (UVP) features. However, additional external protection circuits may be required depending on the application. TI recommends using a voltage regulator and a TVS diode to protect the device from voltage transients and spikes.
  • The recommended decoupling capacitor value for the DRV10983SQPWPRQ1 is 10uF to 22uF, with a voltage rating of 10V to 25V. The capacitor should be placed close to the device's power pins to ensure effective noise filtering and decoupling.
