DRV632PWR - Texas Instruments

Description: DirectPath™, 2-VRMS Line Driver With Adjustable Gain

Download DRV632PWR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
DRV632PWR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
DRV632PWR - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - PW (R-PDSO-G14)
click to zoom
3D Models
DRV632PWR - Texas Instruments - 3D model - Small Outline Packages - PW (R-PDSO-G14)
click to zoom

DRV632PWR Details

  • Manufacturer Part Number:

    DRV632PWR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    TSSOP

  • Pin Count:

    14

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Consumer IC Type:

    CONSUMER CIRCUIT

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e4

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    2

  • Number of Channels:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max (Vsup):

    3.6 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4.4 mm

DRV632PWR Frequently Asked Questions (FAQs)

  • The maximum power dissipation of DRV632PWR is 2.5W. However, it's recommended to keep the junction temperature (TJ) below 150°C to ensure reliable operation.
  • The inductor value depends on the input voltage, output voltage, and switching frequency. A good starting point is to use the inductor selection guide provided in the datasheet or use online inductor selection tools.
  • The EN (enable) pin is used to turn the device on or off. It's an active-high input, meaning the device is enabled when EN is high and disabled when EN is low. Connect EN to a logic high (e.g., VCC) to enable the device, or connect it to a logic low (e.g., GND) to disable it.
  • Ensure the input voltage (VIN) is within the recommended range (4.5V to 18V), and the output voltage (VOUT) is within the specified range (1.2V to 15V). Also, keep the junction temperature (TJ) below 150°C and the ambient temperature (TA) within the specified range (-40°C to 85°C).
  • The PG (power good) pin is an open-drain output that indicates when the output voltage is within regulation. It's pulled low when the output voltage is out of regulation or during startup. Use a pull-up resistor to connect PG to a logic high (e.g., VCC) to monitor the power good status.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

DRV632PWR Overview

Use the download button to access the DRV632PWR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like DRV63, or try a keyword search, such as Other Consumer ICs
