Symbol
PCB Footprints
- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for DS14185WM
- Part Number DS14185WM
- Manufacturer Texas Instruments
- Pin Count 20
- Part Category Integrated Circuit
- Package Category Other
- Footprint Name Other - SOIC127P1032X264-20N
- Released Date Jan 11, 2017
- Last Modified Date Nov 15, 2024 1:35 PM UTC
- Pinout / Pin List Click Here (Member Only)
DS14185WM Details
-
Manufacturer Part Number:
DS14185WM
-
Brand Name:
Texas Instruments
-
Part Life Cycle Code:
Obsolete
-
Part Package Code:
SOIC
-
Package Description:
SOIC-20
-
Pin Count:
20
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.60
-
Manufacturer:
Texas Instruments
-
YTEOL:
0
-
Differential Output:
NO
DS14185WM Frequently Asked Questions (FAQs)
-
Texas Instruments recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat. A minimum of 2oz copper thickness is recommended, and the thermal pad should be connected to a ground plane to reduce thermal resistance.
-
To ensure reliable operation, it's essential to follow the recommended operating conditions, including voltage, current, and temperature ranges. Additionally, consider using thermal management techniques, such as heat sinks or thermal interfaces, to maintain a stable temperature within the operating range.
-
The DS14185WM is designed to withstand moderate vibration levels. However, in high-vibration environments, it's crucial to ensure the device is properly secured to the PCB using a robust mounting method, such as a screw or adhesive, to prevent mechanical stress and damage.
-
While the DS14185WM is designed to operate in a variety of environments, it's not recommended for use in humid or moist environments without proper protection. Consider using conformal coating, potting, or hermetic sealing to protect the device from moisture and humidity.
-
The DS14185WM has built-in ESD protection, but it's still essential to follow proper ESD handling and storage procedures to prevent damage. Use ESD-safe materials, handling tools, and storage containers to minimize the risk of ESD damage.
Trust Checks
System Verified
DS14185WM Overview
Use the download button to access the DS14185WM schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like DS141,
or try a keyword search, such as Line Driver or Receivers
