FDMC8200 - onsemi

Description: Q1: N-Channel Max. RDS(on) = 20 mΩ at VGS = 10 V, ID = 6A Max. RDS(on) = 32 mΩ at VGS = 4.5 V, ID = 5A ; Q2: N-Channel Max. RDS(on) = 9.5 mΩ at VGS = 10 V, ID = 9A Max. RDS(on) = 13.5 mΩ at VGS = 4.5 V, ID = 7A ; RoHS Compliant

Download FDMC8200 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
FDMC8200 - onsemi PCB footprint - Other - Other - FDMC8200-3
click to zoom
3D Models
FDMC8200 - onsemi  - 3D model - Other - FDMC8200-3
click to zoom

FDMC8200 Details

  • Manufacturer Part Number:

    FDMC8200

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    WDFN-8

  • Package Description:

    3 X 3 MM, ROHS COMPLIANT, MLP, 8 PIN

  • Manufacturer Package Code:

    511DE

  • Country Of Origin:

    Thailand

  • ECCN Code:

    EAR99

  • Manufacturer:

    onsemi

  • YTEOL:

    7.07

  • Case Connection:

    DRAIN SOURCE

  • Configuration:

    SERIES, 2 ELEMENTS WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    30 V

  • Drain Current-Max (ID):

    8 A

  • Drain-source On Resistance-Max:

    0.02 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    30 pF

  • JESD-30 Code:

    S-PDSO-N8

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    2

  • Number of Terminals:

    8

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity/Channel Type:

    N-CHANNEL

  • Power Dissipation-Max (Abs):

    1.9 W

  • Pulsed Drain Current-Max (IDM):

    40 A

  • Qualification Status:

    Not Qualified

  • Surface Mount:

    YES

  • Terminal Finish:

    Nickel/Gold/Palladium (Ni/Au/Pd)

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

  • Turn-off Time-Max (toff):

    66 ns

  • Turn-on Time-Max (ton):

    30 ns
