- Part Number LM1496N
- Manufacturer Texas Instruments
- Pin Count 14
- Part Category Integrated Circuit
- Package Category Dual-In-Line Packages
- Footprint Name Dual-In-Line Packages - Molded Dual-In-Line Package (N) Order Number LM1830N NS Package Number N14A
- Released Date Apr 21, 2021
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
LM1496N Details
-
Manufacturer Part Number:
LM1496N
-
Rohs Code:
No
-
Part Life Cycle Code:
Obsolete
-
Package Description:
,
-
Reach Compliance Code:
Unknown
-
HTS Code:
8542.39.00.01
-
Manufacturer:
Texas Instruments
-
YTEOL:
0
LM1496N Frequently Asked Questions (FAQs)
-
The maximum power dissipation of the LM1496N is 1.4W, but it can be increased to 2.5W with proper heat sinking.
-
No, the LM1496N is a quad differential amplifier, not a voltage regulator. It's designed for signal amplification and conditioning, not voltage regulation.
-
To ensure stability, make sure to decouple the power supply lines with capacitors, use a stable voltage reference, and avoid capacitive loads. Also, follow proper PCB layout practices to minimize noise and oscillations.
-
The input impedance of the LM1496N is typically around 10^6 ohms (1MΩ) in differential mode, but it can vary depending on the specific application and circuit configuration.
-
Yes, the LM1496N can operate with a single supply voltage, but the input common-mode voltage range is limited. Make sure to check the datasheet for specific voltage ranges and limitations.
Trust Checks
Community Provided
System Verified
Community Approved
LM1496N Overview
Use the download button to access the LM1496N schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM149,
or try a keyword search, such as Other Signal Circuits
