Texas Instruments provides a recommended PCB layout in the LM25056PSQ/NOPB datasheet, which includes a thermal pad connected to a copper plane on the PCB to dissipate heat. Additionally, it's recommended to use a 2-ounce copper PCB and to keep the thermal pad away from other components to minimize thermal resistance.
To ensure reliable start-up and operation with a wide input voltage range, it's recommended to use a soft-start circuit to limit the inrush current during start-up. Additionally, the input voltage should be filtered to reduce noise and ripple, and the output voltage should be monitored to prevent overvoltage or undervoltage conditions.
The maximum ambient temperature for reliable operation of the LM25056PSQ/NOPB is 85°C, with a derated output power above 60°C. However, the device can operate up to 125°C junction temperature, and the ambient temperature can be higher if the device is properly heat-sinked and the thermal management is adequate.
The LM25056PSQ/NOPB has built-in overcurrent protection (OCP) and short-circuit protection (SCP) features. However, it's recommended to add external protection components, such as fuses or current-sensing resistors, to provide additional protection against overcurrent and short-circuit conditions.
The recommended input capacitor type is a low-ESR ceramic capacitor, such as an X5R or X7R dielectric capacitor. The recommended value is 10uF to 22uF, depending on the input voltage and output current requirements. A larger input capacitor can help to reduce input voltage ripple and improve overall system stability.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LM25056PSQ/NOPB Overview
Use the download button to access the LM25056PSQ/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM250,
or try a keyword search, such as Power Management Circuits
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
