- Part Number LM2621MMX
- Manufacturer Texas Instruments
- Pin Count 8
- Part Category Integrated Circuit
- Package Category Small Outline Packages
- Footprint Name Small Outline Packages - DGK (S-PDSO-G8)
- Released Date Apr 21, 2021
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
LM2621MMX Details
-
Manufacturer Part Number:
LM2621MMX
-
Brand Name:
Texas Instruments
-
Pbfree Code:
No
-
Part Life Cycle Code:
Obsolete
-
Part Package Code:
SOIC
-
Package Description:
MINI, SO-8
-
Pin Count:
8
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.60
-
Manufacturer:
Texas Instruments
-
YTEOL:
0
LM2621MMX Frequently Asked Questions (FAQs)
-
Texas Instruments provides a recommended PCB layout in the datasheet, but it's also important to follow general high-frequency PCB design guidelines, such as using a solid ground plane, minimizing trace lengths, and using bypass capacitors to reduce noise and ringing.
-
The choice of input and output capacitors depends on the specific application and operating conditions. In general, low-ESR capacitors with a high ripple current rating are recommended. The datasheet provides some guidance on capacitor selection, but it's also important to consider factors such as voltage rating, temperature range, and physical size.
-
The LM2621MMX is rated for operation from -40°C to 125°C, but the maximum ambient temperature range may be limited by the specific application and operating conditions. It's important to consider factors such as airflow, thermal resistance, and power dissipation when designing a system using the LM2621MMX.
-
Proper thermal management is critical for the LM2621MMX. This can be achieved through the use of heat sinks, thermal interfaces, and airflow management. The datasheet provides some guidance on thermal management, but it's also important to consider factors such as power dissipation, ambient temperature, and airflow when designing a system.
-
Common failure modes of the LM2621MMX include overvoltage, undervoltage, overheating, and electrical overstress. These can be mitigated through the use of protection circuits, such as overvoltage protection (OVP) and undervoltage protection (UVP), as well as proper thermal management and design practices.
Trust Checks
Community Provided
System Verified
Community Approved
LM2621MMX Overview
Use the download button to access the LM2621MMX schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM262,
or try a keyword search, such as Switching Regulator or Controllers
