LM4308GR - Texas Instruments

LM4308GR Details

• Manufacturer Part Number:

  LM4308GR

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  BGA

• Package Description:

  4 X 4 MM, 1 MM HEIGHT, 0.50 MM PITCH, MICROARRAY-49

• Pin Count:

  49

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Data Input Mode:

  PARALLEL

• Display Mode:

  DOT MATRIX

• Interface IC Type:

  LIQUID CRYSTAL DISPLAY DRIVER

• JESD-30 Code:

  S-PBGA-B49

• Length:

  4 mm

• Multiplexed Display Capability:

  YES

• Number of Functions:

  1

• Number of Segments:

  18

• Number of Terminals:

  49

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TFBGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, THIN PROFILE, FINE PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.1 mm

• Supply Voltage-Max:

  2 V

• Supply Voltage-Min:

  1.6 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  4 mm
