LM4781TA - Texas Instruments

LM4781TA Details

• Manufacturer Part Number:

  LM4781TA

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SFM

• Package Description:

  PLASTIC, TO-220, 27 PIN

• Pin Count:

  3

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• JESD-30 Code:

  R-PZIP-T27

• JESD-609 Code:

  e0

• Moisture Sensitivity Level:

  1

• Number of Channels:

  3

• Number of Functions:

  1

• Number of Terminals:

  27

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Output Power-Nom:

  35 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP27,.16,.16,40

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  150 mA

• Supply Voltage-Max (Vsup):

  70 V

• Supply Voltage-Min (Vsup):

  20 V

• Surface Mount:

  NO

• Temperature Grade:

  OTHER

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1 mm

• Terminal Position:

  ZIG-ZAG
