LM48413TL - Texas Instruments

LM48413TL Details

• Manufacturer Part Number:

  LM48413TL

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOIC

• Package Description:

  2 X 2.20 MM, ROHS COMPLIANT, MICRO, SMD-18

• Pin Count:

  18

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Bandwidth-Nom:

  22 kHz

• Consumer IC Type:

  CLASS D AUDIO AMPLIFIER

• Harmonic Distortion:

  1%

• JESD-30 Code:

  R-PDSO-G18

• Length:

  2.25 mm

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  18

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Power-Nom:

  1.2 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VSSOP

• Package Equivalence Code:

  BGA18,4X5,20/17

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  0.675 mm

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  2.4 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Width:

  2.047 mm
