LMG3410R150RWHR - Texas Instruments

Description: LMG341xR150 600-V, 150-mΩ, GaN FET with Integrated Driver and Protection

Download LMG3410R150RWHR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LMG3410R150RWHR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
LMG3410R150RWHR - Texas Instruments PCB footprint - Other - Other - RWH0032A_1
click to zoom
3D Models
LMG3410R150RWHR - Texas Instruments - 3D model - Other - RWH0032A_1
click to zoom

LMG3410R150RWHR Details

  • Manufacturer Part Number:

    LMG3410R150RWHR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Date Of Intro:

    2019-06-13

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    POWER SUPPLY SUPPORT CIRCUIT

  • JESD-30 Code:

    S-PQCC-N32

  • JESD-609 Code:

    e4

  • Length:

    8 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    32

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HQCCN

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.9 mm

  • Supply Voltage-Max (Vsup):

    18 V

  • Supply Voltage-Min (Vsup):

    9.5 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    8 mm

LMG3410R150RWHR Frequently Asked Questions (FAQs)

  • The maximum junction temperature (Tj) that the LMG3410R150RWHR can operate at is 150°C. However, it's recommended to keep the junction temperature below 125°C for optimal performance and reliability.
  • To ensure proper cooling, it's recommended to use a heat sink with a thermal resistance of less than 1°C/W. Additionally, ensure good airflow around the device and avoid blocking the airflow with other components or obstacles.
  • The recommended PCB layout for the LMG3410R150RWHR involves keeping the high-frequency nodes (e.g., drain and source) as close as possible to the device, using a solid ground plane, and minimizing the length of the drain and source traces. It's also recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane.
  • To protect the LMG3410R150RWHR from overvoltage and overcurrent, it's recommended to use a voltage regulator or a DC-DC converter with overvoltage protection (OVP) and overcurrent protection (OCP). Additionally, consider using a fuse or a current-limiting resistor in series with the device.
  • The recommended gate drive voltage for the LMG3410R150RWHR is between 10V and 15V. However, the device can operate with a gate drive voltage as low as 6V, but the switching performance may be affected.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

LMG3410R150RWHR Overview

Use the download button to access the LMG3410R150RWHR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LMG34, or try a keyword search, such as Power Management Circuits

About Texas Instruments

Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
