LMK61E0M-SIAT - Texas Instruments

Description: XO (Standard) LVCMOS 50 MHz ~ 200 MHz Programmable Oscillator 3.3V Enable/Disable 8-SMD Module

Download LMK61E0M-SIAT Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
LMK61E0M-SIAT - Texas Instruments PCB footprint - Other - Other - SIA Package 8-Pin QFM
click to zoom
3D Models
LMK61E0M-SIAT - Texas Instruments  - 3D model - Other - SIA Package 8-Pin QFM
click to zoom

LMK61E0M-SIAT Details

  • Manufacturer Part Number:

    LMK61E0M-SIAT

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Date Of Intro:

    2017-01-20

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Additional Feature:

    ENABLE/DISABLE FUNCTION

  • Frequency Adjustment-Mechanical:

    NO

  • Frequency Stability:

    25%

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    8

  • Operating Frequency-Max:

    200 MHz

  • Operating Frequency-Min:

    50 MHz

  • Operating Frequency-Nom:

    200 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Oscillator Type:

    LVCMOS

  • Output Load:

    50 OHM

  • Physical Dimension:

    7.0mm x 5.0mm x 1.15mm

  • Supply Current-Max:

    180 mA

  • Supply Voltage-Max:

    3.465 V

  • Supply Voltage-Min:

    3.135 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    YES

  • Symmetry-Max:

    55/45 %

  • Technology:

    LVCMOS

  • Terminal Finish:

    Nickel/Gold (Ni/Au)
