NCP347MTAHTBG - onsemi

Description: Battery Management OVER VLTG PROTECTION Positive Overvoltage Protection Controller with Internal Low RON NMOS FET and Status FLAG

Download NCP347MTAHTBG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCP347MTAHTBG - onsemi PCB footprint - Other - Other - DFN8 5x6, 1.27P Dual Flag (SO8FL−Dual) CASE 506BT ISSUE E_1
click to zoom
3D Models
NCP347MTAHTBG - onsemi  - 3D model - Other - DFN8 5x6, 1.27P Dual Flag (SO8FL−Dual) CASE 506BT ISSUE E_1
click to zoom

NCP347MTAHTBG Details

  • Manufacturer Part Number:

    NCP347MTAHTBG

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    WDFN10, 2.5x2 mm, 0.5P

  • Package Description:

    WDFN-10

  • Pin Count:

    10

  • Manufacturer Package Code:

    516AA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    INPUT FAULT PROTECTION CONTROLLER

  • JESD-30 Code:

    R-PDSO-N10

  • JESD-609 Code:

    e3

  • Length:

    2.5 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    10

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Equivalence Code:

    SOLCC8,.08,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    0.8 mm

  • Supply Current-Max (Isup):

    0.25 mA

  • Supply Voltage-Max (Vsup):

    28 V

  • Supply Voltage-Min (Vsup):

    1.2 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    2 mm

NCP347MTAHTBG Frequently Asked Questions (FAQs)

  • A good PCB layout for NCP347MTAHTBG involves keeping the input and output capacitors close to the device, using a solid ground plane, and minimizing the length of the traces between the device and the capacitors. Additionally, it's recommended to use a separate power plane for the input voltage and to keep the output voltage plane as close to the device as possible.
  • To ensure the stability of the output voltage of NCP347MTAHTBG, it's essential to choose the right output capacitor value and type. A minimum output capacitance of 10uF is recommended, and the capacitor should have a low ESR (Equivalent Series Resistance) to minimize voltage ripple. Additionally, the output voltage should be decoupled from the input voltage using a decoupling capacitor.
  • The maximum ambient temperature that NCP347MTAHTBG can operate at is 125°C. However, the device's performance and reliability may degrade at higher temperatures, so it's recommended to operate it at a lower temperature if possible.
  • Yes, NCP347MTAHTBG is suitable for high-reliability applications. It's built with a robust design and has undergone rigorous testing to ensure its reliability and performance. However, it's essential to follow proper design and manufacturing guidelines to ensure the device operates within its specified parameters.
  • To troubleshoot issues with NCP347MTAHTBG, start by checking the input voltage and current, output voltage and current, and the device's operating temperature. Verify that the device is properly soldered and that the PCB layout is correct. Check for any signs of physical damage or overheating. If the issue persists, consult the datasheet and application notes or contact onsemi's technical support for further assistance.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

NCP347MTAHTBG Overview

Use the download button to access the NCP347MTAHTBG schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NCP34, or try a keyword search, such as Power Management Circuits

Parts related to NCP347MTAHTBG

Showing 0 results

NCP347MTAHTBG Alternates

Showing results

Image Part Number Model
Part Image NCP347MTAFTBG onsemi

Fixed, 1 Channel, PDSO10

Part Image NCP347MTAETBG onsemi

Fixed, 1 Channel, PDSO10
