PADS9218RHAT - Texas Instruments

PADS9218RHAT Details

• Manufacturer Part Number:

  PADS9218RHAT

• Brand Name:

  Texas Instruments

• Part Life Cycle Code:

  Obsolete

• Package Description:

  HVQCCN-56

• HTS Code:

  8542.39.00.30

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Analog Input Voltage-Max:

  5.25 V

• Analog Input Voltage-Min:

  4.75 V

• Conversion Time-Max:

  0.256 µs

• Converter Type:

  ADC, SUCCESSIVE APPROXIMATION

• JESD-30 Code:

  S-PQCC-N56

• Length:

  7 mm

• Linearity Error-Max (EL):

  0.001716%

• Number of Analog In Channels:

  8

• Number of Bits:

  18

• Number of Functions:

  1

• Number of Terminals:

  56

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  BINARY, 2S COMPLEMENT BINARY

• Output Format:

  SERIAL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC56,.27SQ,16

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Sample Rate:

  1 MHz

• Seated Height-Max:

  1 mm

• Supply Current-Max:

  43 mA

• Supply Voltage-Min:

  1.75 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Width:

  7 mm
