REF7012QFKHT - Texas Instruments

REF7012QFKHT Details

• Manufacturer Part Number:

  REF7012QFKHT

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Analog IC - Other Type:

  THREE TERMINAL VOLTAGE REFERENCE

• Input Voltage-Max:

  18 V

• Input Voltage-Min:

  3 V

• JESD-30 Code:

  S-CQCC-N8

• Length:

  5 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.01 A

• Output Voltage-Max:

  1.2503125 V

• Output Voltage-Min:

  1.249688 V

• Output Voltage-Nom:

  1.25 V

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  HQCCN

• Package Equivalence Code:

  LCC8,.2SQ

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG

• Seated Height-Max:

  1.6 mm

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  2.75 V

• Supply Voltage-Nom (Vsup):

  3 V

• Surface Mount:

  YES

• Temp Coef of Voltage-Max:

  2 ppm/°C

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  QUAD

• Trim/Adjustable Output:

  NO

• Voltage Tolerance-Max:

  0.025%

• Width:

  5 mm
